Autonics Switching Mode Power Supply (SPB-030-12) In 100~240 VAC, Out 12 VDC (2.5 Amp)

Rs 8,200.00

Model: SPB-030-12

Output power 30W
Input Voltage 100-240VAC~ 50/60Hz
Permissible voltage 85-264VAC~ 50/60Hz, 120-370VDC
Output_Voltage 12VDC
Output_Current 2.5A
Mounting type DIN Rail
Protection Over-Current/Inrush Current/Output Short-Circuit/Output Low-Voltage Indicate
Input_Frequency 50/60Hz
Input_Efficiency_100VAC~ 0.82
Input_Efficiency_240VAC~ 0.83
Input_Current consumption_100VAC~ 0.63A
Input_Current consumption_240VAC~ 0.35A
Output type_Voltage adjustment range Max. 10%
Output type_Input fluctuation ratio Max. 0.5%
Output type_Load fluctuation ratio Max. 1%
Output type_Ripple&Ripple noise Max. 1%
Protection structure IP20(IEC standard)
Environment_Ambient temperature -10 to 50℃, storage: -25 to 65℃ (surrounding air temp.: Max. 40℃)
Environment_Ambient humidity 25 to 85%RH, storage: 25 to 90%RH
Weight Approx. 249g(approx. 176g)
