Schneider DC 2pole SPD Surge Protection Device 40kA 1000V DC
Rs 2,850.00
product : DC surge protection device
number of poles : 2
output type : Contact
working voltage : DC (direct current)
rated operational voltage : 1000V DC
maximum discharge current : 40kA
(In) nominal discharge current : 20kA
disconnector type : Integrated disconnector
mounting on : Din rail
termination type : screw terminal
Cash on delivery available
- Description
- Reviews (1)
Description
- This is the 2pole DC direct current surge protection device used mostly in solar and dc installations.
- It allows the quick replacement of damaged cartridges easily.
- The short circuit breaking capacity and the total discharge current is 40kA.
- The In nominal discharge current is 20kA.
- This device is must recommended to protect against indirect lightning strikes.
- It is the most using safety device in solar systems.
- It can be turned over to allow the phase/neutral cables to enter through either the top or the bottom.
- It’s Uc maximum continuous operating voltage is 1000VDC.
- The Up protection level is 4.0kV.
- The operating temperature is -25°C to 60°C and the storage temperature is -40°C to 85°C.
Jamil manj –
Good product for solar safety
