• Schneider (ABL8MEM05040) 1 or 2 phase 100-240 VAC / 5 VDC 4 A Regulated SMPS Power Supply

    0 out of 5

    Model:ABL8MEM05040

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…240 V AC phase to phase, terminal(s): L1-L2
    100…240 V AC single phase, terminal(s): N-L1
    120…250 V DC
    rated power in W
    20W
    output voltage
    5 V DC
    power supply output current
    4A
    Complementary
    Power Factor
    0.5
    efficiency
    75%
    Output voltage adjustment
    4.75…6.25 V adjustable
    power dissipation in W
    6.7W
    current consumption
    0.35 A at 240 V
    0.55 A at 100 V
    Hold-up time
    >= 10 ms at 100 V
    residual ripple
    250 mV
    connections – terminals
    For input connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    For output connection: screw type terminals, connection capacity: 4 x 0.14…4 x 2.5 mm AWG 26…AWG 14
    status LED
    1 LED (green)output voltage:
    depth
    59mm
    height
    100mm
    width
    54mm



    Rs 15,500.00
  • Schneider (ABL8MEM12020) 1 or 2 phase 100-240 VAC / 12 VDC 2 A Regulated SMPS Power Supply

    0 out of 5

    Model: ABL8MEM12020

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…240 V AC phase to phase, terminal(s): L1-L2
    100…240 V AC single phase, terminal(s): N-L1
    120…250 V DC
    rated power in W
    25W
    output voltage
    12-15 V DC
    power supply output current
    2.1A
    Power Factor
    0.5
    efficiency
    80%
    Output voltage adjustment
    11.4…15 V adjustable
    power dissipation in W
    6.2W
    current consumption
    0.35 A at 240 V
    0.6 A at 100 V
    Hold-up time
    >= 10 ms at 100 V
    residual ripple
    250 mV
    connections – terminals
    For input connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    For output connection: screw type terminals, connection capacity: 4 x 0.14…4 x 2.5 mm AWG 26…AWG 14
    status LED
    1 LED (green)output voltage:
    depth
    59mm
    height
    100mm
    width
    54mm



    Rs 13,900.00
  • Schneider (ABL8MEM24003) 1 or 2 phase 100-240 VAC / 24 VDC 0.3 A Regulated SMPS Power Supply

    0 out of 5

    Model:ABL8MEM24003

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…240 V AC phase to phase, terminal(s): L1-L2
    100…240 V AC single phase, terminal(s): N-L1
    120…250 V DC
    rated power in W
    7W
    output voltage
    24 V DC
    power supply output current
    0.3A
    Power Factor
    0.5
    efficiency
    78%
    Output voltage adjustment
    22.2…28.8 V adjustable
    power dissipation in W
    2W
    current consumption
    0.18 A at 240 V
    0.25 A at 100 V
    Hold-up time
    >= 10 ms at 100 V
    >= 150 ms at 230 V
    residual ripple
    250 mV
    connections – terminals
    For input connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    For output connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    status LED
    1 LED (green)output voltage:
    depth
    59mm
    height
    100mm
    width
    36mm



    Rs 14,200.00
  • Schneider (CA2KN40F7) Control Relay 4 NO 110 VAC coil

    0 out of 5

    Model: CA2KN40F7

    range
    TeSys
    product name
    TeSys CAK
    product or component type
    Control relay
    device short name
    CA2K
    contactor application
    Control circuit
    utilisation category
    DC-13
    AC-15
    pole contact composition
    4 NO
    control circuit type
    AC at 50/60 Hz
    [Uc] control circuit voltage
    110 V AC 50/60 Hz

    [Ith] conventional free air thermal current
    10A (at 50C)
    Irms rated making capacity
    110A conforming to IEC 60947
    associated fuse rating
    10A gG conforming to IEC 60947
    10A gG conforming to VDE 0660
    [Ui] rated insulation voltage
    690V conforming to IEC 60947
    750V conforming to VDE 0110 group C
    690V conforming to BS 5424
    600V conforming to CSA C22.2 No 14
    mounting support
    Rail
    Plate
    connections – terminals
    Screw clamp terminals 1 cable(s) 1.54mmsolid
    Screw clamp terminals 2 cable(s) 1.54mmsolid
    Screw clamp terminals 1 cable(s) 0.754mmflexible with cable end
    Screw clamp terminals 2 cable(s) 0.754mmflexible without cable end
    Screw clamp terminals 1 cable(s) 0.341.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 0.341.5mmflexible without cable end
    tightening torque
    1.3N.m – on screw clamp terminals – with screwdriver flat 6 mm
    1.3N.m – on screw clamp terminals – with screwdriver Philips No 26mm
    control circuit voltage limits
    Drop-out: 0.2…0.75 Uc (at <50C)
    Operational: 0.8…1.15 Uc (at <50C)
    operating time
    10…20 ms coil de-energisation and NO opening
    10…20 ms coil energisation and NO closing
    mechanical durability
    10Mcycles
    maximum operating rate
    10000cyc/h
    immunity to microbreaks
    2ms
    inrush power in VA
    30VA (at 20C)
    hold-in power consumption in VA
    4.5VA (at 20C)
    heat dissipation
    1.3W
    minimum switching voltage
    17V
    minimum switching current
    5mA
    non overlap distance
    0.5mm
    insulation resistance
    > 10 MOhm
    height
    58mm
    width
    45mm
    depth
    57mm
    net weight
    0.18kg



    Rs 2,900.00
  • Schneider (CAE22B5) 2NO + 2NC Control Relay 24 VAC

    0 out of 5

    Model: CAE22B5

    range
    EasyPact
    product name
    EasyPact TVS
    product or component type
    Control relay
    device short name
    CAE
    contactor application
    Control circuit
    colour
    Grey (RAL 7011)
    utilization category
    AC-15
    AC-14
    pole contact composition
    2 NO + 2 NC
    [Ue] rated operational voltage
    <= 690 V AC
    control circuit type
    AC at 50 Hz
    [Uc] control circuit voltage
    24 V AC 50 Hz
    [Uimp] rated impulse withstand voltage
    6kV conforming to IEC 60947
    [Ith] conventional free air thermal current
    10A (at 40C)
    Irms rated making capacity
    140A at 690 V AC conforming to IEC 60947-5-1
    [Icw] rated short-time withstand current
    120A – 500 ms
    140A – 100 ms
    associated fuse rating
    10A gG at 690 V conforming to IEC 60947-5-1
    [Ui] rated insulation voltage
    690V conforming to IEC 60947-5-1
    mounting support
    Rail
    Plate
    connections – terminals
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: solid without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: solid without cable end
    tightening torque
    1.2N.m – on screw clamp terminals – with screwdriver Philips No 2
    control circuit voltage limits
    Operational: 0.85…1.1 Uc at 50 Hz
    Drop-out: 0.3…0.6 Uc
    operating time
    4…19 ms coil energisation and NC opening
    12…22 ms coil energisation and NO closing
    4…12 ms coil de-energisation and NC opening
    6…17 ms coil de-energisation and NO closing
    mechanical durability
    10Mcycles
    maximum operating rate
    180cyc/mn
    inrush power in VA
    70VA 50 Hz (at 20C)
    hold-in power consumption in VA
    8VA 50 Hz (at 20C)
    minimum switching voltage
    17V
    minimum switching current
    5mA
    non-overlap time
    1.5ms on energisation between NC and NO contact
    1.5ms on de-energisation between NC and NO contact
    insulation resistance
    > 10 MOhm
    mechanical robustness
    Shocks control relay open: 7 Gn for 11 ms
    Shocks control relay closed: 10 Gn for 11 ms
    Vibrations control relay open: 1.5 Gn, 5…300 Hz
    Vibrations control relay closed: 3 Gn, 5…300 Hz
    height
    74mm
    width
    45mm
    depth
    80mm
    net weight
    0.28kg



    Rs 3,200.00
  • Schneider (CAE40N5) 4 NO Control Relay 415 VAC

    0 out of 5

    Model: CAE40N5

    product or component type
    Control relay
    device short name
    CAE
    contactor application
    Control circuit
    colour
    Grey (RAL 7011)
    Complementary
    utilisation category
    AC-15
    AC-14
    pole contact composition
    4 NO
    [Ue] rated operational voltage
    <= 690 V AC
    control circuit type
    AC at 50 Hz
    [Uc] control circuit voltage
    415 V AC 50 Hz
    [Uimp] rated impulse withstand voltage
    6kV conforming to IEC 60947
    [Ith] conventional free air thermal current
    10A (at 40C)
    Irms rated making capacity
    140A at 690 V AC conforming to IEC 60947-5-1
    [Icw] rated short-time withstand current
    120A – 500 ms
    140A – 100 ms
    associated fuse rating
    10A gG at 690 V conforming to IEC 60947-5-1
    [Ui] rated insulation voltage
    690V conforming to IEC 60947-5-1
    mounting support
    Rail
    Plate
    connections – terminals
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: solid without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: solid without cable end
    tightening torque
    1.2N.m – on screw clamp terminals – with screwdriver Philips No 2
    control circuit voltage limits
    Operational: 0.85…1.1 Uc at 50 Hz
    Drop-out: 0.3…0.6 Uc
    operating time
    12…22 ms coil energisation and NO closing
    6…17 ms coil de-energisation and NO closing
    mechanical durability
    10Mcycles
    maximum operating rate
    180cyc/mn
    inrush power in VA
    70VA 50 Hz (at 20C)
    hold-in power consumption in VA
    8VA 50 Hz (at 20C)
    minimum switching voltage
    17V
    minimum switching current
    5mA
    insulation resistance
    > 10 MOhm
    mechanical robustness
    Shocks control relay open: 7 Gn for 11 ms
    Shocks control relay closed: 10 Gn for 11 ms
    Vibrations control relay open: 1.5 Gn, 5…300 Hz
    Vibrations control relay closed: 3 Gn, 5…300 Hz
    height
    74mm
    width
    45mm
    depth
    80mm
    net weight
    0.28kg



    Rs 3,200.00
  • Schneider (DT40) Miniature Circuit Breaker 1 pole + neutral C-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 4 Amp
    • 6 Amp
    • 10 Amp
    • 16 Amp
    • 20 Amp
    • 25 Amp
    • 32 Amp
    • 40 Amp
    Rs 3,600.00
  • Schneider (DT40) Miniature Circuit Breaker 3 Pole + Neutral C-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 6 Amp
    • 10 Amp
    • 16 Amp
    • 20 Amp
    • 32 Amp
    • 40 Amp
    Rs 13,000.00
  • Schneider (DT60) Miniature Circuit Breaker 4 pole C-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 40 Amp
    • 63 Amp
    Rs 7,000.00
  • Schneider (EM1200) 15A VAF, PF Power and Energy Meter

    0 out of 5



    • Product: Digital AC Energy Meter
    • Phase: 3 phase
    • Rating: 15 A
    • Model: EM1200
    • Accuracy Class 1.0, 0.5
    • Elegant single row, backlit LCD display
    • Monitors electrical parameters : Volts, Amps, F & PF Simultaneously, W/VA/Var
    • Integrated Parameters : Wh /Vah/Varh
    • Runhrs, Onhrs & Interrupts Monitoring
    • Three parameters, name and value at single glance with direct reading of primary values
    • User programmable
    • Delta/STAR/2Ph/1ph
    • PT/ CT primary & Secondary
    • Smart line indicators to check the healthy phase of input voltage
    • UL, C UL Listed, CE, C-Tick certified
    • Direct Connection of metering voltage input upto 480V ac L-L
    • Pulse output / RS485 communication port with Modbus RTU protocol
    • Reduce energy costs by tracking energy consumption and backup of last cleared energy values
    • Auto Scrolling enables you to monitor group of parameter sequentially
    • Auto Scaling Capability in variance of Kilo, Mega, Giga
    • Intuitive function keys for easy navigation with vertical expansion of display pages
    • User Selectable default display page through keypad lock
    • Safeguard access to setup parameters with unique password protection
    • Ensure accurate wiring using the terminal board labeling
    • Seamless integration into any modbus compatible SCADA- Energy Management System (EMS)



    Rs 6,000.00
  • Schneider (LA2KT2E) TeSys K -Time delay auxiliary contact block 24-48 V AC/DC (1-30 sec)

    0 out of 5

    Product: Time delay auxiliary contact block

    Model: LA2KT2E

    Brand: Schneider

    Voltage: 24-48 V AC/DC

    Timer type: On delay

    Pole contact composition: 1 C/O

    Time delay range: 1-30 sec

    Height: 1.06 in (27 mm)

    Width: 1.50 in (38 mm)

    Depth: 1.50 in (38 mm)

    Terminals: screw terminals

    Rs 4,500.00
  • Schneider (LA4DT0U) On Delay Electronic Timer 0.1~2 s , 24~250 V DC/AC

    0 out of 5

    Model:LA4DT0U

    product or component type
    Serial timer modules
    time delay range
    0.1~2 s
    poles description
    3P
    timer type On delay
    mounting location
    Top
    [Uc] control circuit voltage
    24…250 V AC 50/60 Hz
    24…250 V DC
    control circuit voltage limits
    By mechanical contact: 0.8…1.1 Uc
    [Ui] rated insulation voltage
    250V conforming to IEC 60947-1
    connections – terminals
    Control circuit: connector 1 cable(s) 1mmflexible with cable end
    Control circuit: connector 1 cable(s) 1mmsolid with cable end
    Control circuit: connector 2 cable(s) 2.5mmflexible without cable end
    Control circuit: connector 2 cable(s) 2.5mmsolid without cable end
    electrical durability
    30Mcycles
    timer type
    On delay
    time delay range
    0.1~2 s
    reset time
    150ms during time delay
    50ms after time delay
    local signalling
    Illuminates during time delay by LED
    [Ures] residual voltage
    3.3V
    net weight
    0.04kg



    Rs 6,450.00
  • Schneider (LA4DT2U) On Delay Electronic Timer 1.5~30 s , 24~250 V DC/AC

    0 out of 5

    Model:LA4DT2U

    product or component type
    Serial timer modules
    time delay range 1.5~30 s
    poles description
    3P
    timer type On delay
    mounting location
    Top
    [Uc] control circuit voltage
    24…250 V AC 50/60 Hz
    24…250 V DC
    control circuit voltage limits
    By mechanical contact: 0.8…1.1 Uc
    [Ui] rated insulation voltage
    250V conforming to IEC 60947-1
    connections – terminals
    Control circuit: connector 1 cable(s) 1mmflexible with cable end
    Control circuit: connector 1 cable(s) 1mmsolid with cable end
    Control circuit: connector 2 cable(s) 2.5mmflexible without cable end
    Control circuit: connector 2 cable(s) 2.5mmsolid without cable end
    electrical durability
    30Mcycles
    timer type
    On delay
    time delay range
    1.5~30 s
    reset time
    150ms during time delay
    50ms after time delay
    local signalling
    Illuminates during time delay by LED
    [Ures] residual voltage
    3.3V
    net weight
    0.04kg



    Rs 6,450.00
  • Schneider (LA4DT4U) On Delay Electronic Timer 25~500 s , 24~250 V DC/AC

    0 out of 5

    Model:LA4DT4U

    product or component type
    Serial timer modules
    time delay range 25~500 sec
    poles description
    3P
    timer type On delay
    Complementary
    mounting location
    Top
    [Uc] control circuit voltage
    24…250 V AC 50/60 Hz
    24…250 V DC
    control circuit voltage limits
    By mechanical contact: 0.8…1.1 Uc
    [Ui] rated insulation voltage
    250V conforming to IEC 60947-1
    connections – terminals
    Control circuit: connector 1 cable(s) 1mmflexible with cable end
    Control circuit: connector 1 cable(s) 1mmsolid with cable end
    Control circuit: connector 2 cable(s) 2.5mmflexible without cable end
    Control circuit: connector 2 cable(s) 2.5mmsolid without cable end
    electrical durability
    30Mcycles
    timer type
    On delay
    time delay range
    25~500 sec
    reset time
    150ms during time delay
    50ms after time delay
    local signalling
    Illuminates during time delay by LED
    [Ures] residual voltage
    3.3V
    net weight
    0.04kg



    Rs 6,450.00
  • Schneider (LA4FRCF) Suppressor Module 50~110 VAC

    0 out of 5

    Model: LA4FRCF

    range
    TeSys
    device short name
    LA4F
    product or component type
    Suppressor module
    product compatibility
    LC1F
    mounting mode
    By clips
    suppressor technology
    RC circuit
    [Uc] control circuit voltage
    50~110 V AC
    maximum peak voltage
    3 Uc
    net weight
    0.04kg



    Rs 8,500.00
  • Schneider (LA4FRCP) Suppressor Module 127~240 VAC

    0 out of 5

    Model: LA4FRCP

    range
    TeSys
    device short name
    LA4F
    product or component type
    Suppressor module
    product compatibility
    LC1F
    mounting mode
    By clips
    suppressor technology
    RC circuit
    [Uc] control circuit voltage
    127~240 V AC
    maximum peak voltage
    3 Uc
    net weight
    0.04kg



    Rs 8,500.00
  • Schneider (LADR0) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model: LADR0

    time delayrange: 0.1-3 s

    timer type: Off delay

    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A AC conforming to IEC 60947-5-1
    250A DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    Off delay
    time delay range
    0.1-3 s
    insulation resistance
    > 10 MOhm



    Rs 7,900.00
  • Schneider (LADR2) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model: LADR2

    time delay range 0.1-30 s
    timer type Off delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    Complementary
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    Off delay
    time delay range
    0.1-30 s
    insulation resistance
    > 10 MOhm



    Rs 6,900.00
  • Schneider (LADR4) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model:LADR4

    time delay range
    10-180 s
    timer type off delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    Off delay
    time delay range
    10-180 s
    insulation resistance
    > 10 MOhm



    Rs 6,900.00
  • Schneider (LADS2) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model:LADS2

    time delay range 1-30 s
    timer type On delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    Complementary
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    On delay
    time delay range
    1-30 s
    insulation resistance
    > 10 MOhm



    Rs 7,500.00
  • Schneider (LADT0) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model: LADT0

    time delay range 0.1-3 s
    timer type On delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    Complementary
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    On delay
    time delay range
    0.1-3 s
    insulation resistance
    > 10 MOhm



    Rs 6,500.00
  • Schneider (LADT2) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model:LADT2

    time delay range 0.1-30 s
    timer type On delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    Complementary
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    On delay
    time delay range
    0.1-30 s
    insulation resistance
    > 10 MOhm



    Rs 6,500.00
  • Schneider (LADT4) Time Delay Auxiliary Contact Block 1 NO + 1 NC Screw Clamp Terminals

    0 out of 5

    Model: LADT4

    time delay range 10-180 s
    timer type On delay
    product or component type
    Time delay auxiliary contact block
    pole contact composition
    1 NO + 1 NC
    connections – terminals
    Screw clamp terminals 1 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 1 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible with cable end
    Screw clamp terminals 2 cable(s) 12.5mmflexible without cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 1 cable(s) 12.5mmsolid without cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid with cable end
    Screw clamp terminals 2 cable(s) 12.5mmsolid without cable end
    Complementary
    mounting location
    Front
    [Ui] rated insulation voltage
    600V – certifications UL
    690V conforming to IEC 60947-5-1
    600V – certifications CSA
    [Ue] rated operational voltage
    690 V AC 25…400 Hz
    [Ith] conventional free air thermal current
    10A (at 60C)
    Irms rated making capacity
    140A at <= 690 V AC conforming to IEC 60947-5-1
    250A at <= 690 V DC conforming to IEC 60947-5-1
    permissible short-time rating
    100A 60C 1 s
    120A 60C 500 ms
    140A 60C 100 ms
    protection type
    GG fuse 10A
    associated fuse rating
    10A gG conforming to IEC 60947-5-1
    mechanical durability
    5Mcycles
    minimum switching current
    5mA
    minimum switching voltage
    17V
    non-overlap time
    1.5ms on de-energisation no overlap between NC and NO contact
    1.5ms on energisation no overlap between NC and NO contact
    timer type
    On delay
    time delay range
    10-180 s
    insulation resistance
    > 10 MOhm



    Rs 6,800.00
  • Schneider (LT4706M7A) EOCR Electronic Over Current Relay 0.5~6 A , 200~240 VAC

    0 out of 5

    Model: LT4706M7A

    product or component type
    Electronic over current relay
    device short name
    LT47
    device application
    Protection
    relay application
    Locked rotor, mechanical jamming I > 3 x Isetting
    Sensitivity to phase failure
    Overload Imax > Isetting
    [Us] rated supply voltage
    200…240 V AC
    thermal protection adjustment range
    0.56A
    [Ui] rated insulation voltage
    Power circuit: 600V AC conforming to CSA
    Power circuit: 600V AC conforming to UL
    Power circuit: 690V AC conforming to IEC 60947-4-1
    network frequency
    50…60 Hz
    mounting support
    Rail
    tripping threshold
    0.5…5 A
    electromagnetic compatibility
    Resistance to electrostatic discharge: 8 kV in open air conforming to IEC 61000-4-2
    Resistance to electrostatic discharge: 6 kV in direct mode conforming to IEC 61000-4-2
    Conducted emission: class A conforming to EN 55011
    Immunity to electromagnetic interference: 10 V/m conforming to IEC 61000-4-3
    Immunity to fast transients: 2 kV conforming to IEC 61000-4-4
    Surge withstand: 6 kV conforming to IEC 61000-4-5
    Conducted HF disturbances: 10 V conforming to IEC 61000-4-6
    auxiliary contact composition
    1 NO + 1 NC
    [Ith] conventional free air thermal current
    3A for signalling circuit
    associated fuse rating
    3A gG for signalling circuit
    3A BS for signalling circuit
    [Uimp] rated impulse withstand voltage
    6kV
    time range
    1…120 s – control type R-time
    0.3…30 s – control type O-time
    local signalling
    1 LED (green)
    1 LED (red)
    control type
    automatic: reset
    connections – terminals
    Signalling circuit: screw clamp terminals 1 12.5mm – cable stiffness: flexible with cable end
    Signalling circuit: screw clamp terminals 1 12.5mm – cable stiffness: flexible without cable end
    Signalling circuit: screw clamp terminals 2 12.5mm – cable stiffness: flexible with cable end
    Signalling circuit: screw clamp terminals 2 12.5mm – cable stiffness: flexible without cable end
    tightening torque
    Signalling circuit: 1.7N.m M3.5
    height
    70.3mm
    width
    71mm
    depth
    77.2mm
    net weight
    0.192kg



    Rs 13,900.00
  • Schneider (LT4760M7A) EOCR Electronic Over Current Relay 5~60 A , 200~240 VAC

    0 out of 5

    Model: LT4760M7A

    product or component type
    Electronic over current relay
    device short name
    LT47
    device application
    Protection
    relay application
    Overload Imax > Isetting
    Locked rotor, mechanical jamming I > 3 x Isetting
    Sensitivity to phase failure
    [Us] rated supply voltage
    200…240 V AC
    thermal protection adjustment range
    5~60A
    [Ui] rated insulation voltage
    Power circuit: 600V AC conforming to CSA
    Power circuit: 600V AC conforming to UL
    Power circuit: 690V AC conforming to IEC 60947-4-1
    network frequency
    50…60 Hz
    mounting support
    Rail
    tripping threshold
    5…50 A
    electromagnetic compatibility
    Resistance to electrostatic discharge: 8 kV in open air conforming to IEC 61000-4-2
    Resistance to electrostatic discharge: 6 kV in direct mode conforming to IEC 61000-4-2
    Conducted emission: class A conforming to EN 55011
    Immunity to electromagnetic interference: 10 V/m conforming to IEC 61000-4-3
    Immunity to fast transients: 2 kV conforming to IEC 61000-4-4
    Surge withstand: 6 kV conforming to IEC 61000-4-5
    Conducted HF disturbances: 10 V conforming to IEC 61000-4-6
    auxiliary contact composition
    1 NO + 1 NC
    [Ith] conventional free air thermal current
    3A for signalling circuit
    associated fuse rating
    3A gG for signalling circuit
    3A BS for signalling circuit
    [Uimp] rated impulse withstand voltage
    6kV
    time range
    1…120 s – control type R-time
    0.3…30 s – control type O-time
    local signalling
    1 LED (green)
    1 LED (red)
    control type
    automatic: reset
    connections – terminals
    Signalling circuit: screw clamp terminals 1 12.5mm – cable stiffness: flexible with cable end
    Signalling circuit: screw clamp terminals 1 12.5mm – cable stiffness: flexible without cable end
    Signalling circuit: screw clamp terminals 2 12.5mm – cable stiffness: flexible with cable end
    Signalling circuit: screw clamp terminals 2 12.5mm – cable stiffness: flexible without cable end
    tightening torque
    Signalling circuit: 1.7N.m M3.5
    height
    70.3mm
    width
    71mm
    depth
    77.2mm
    net weight
    0.192kg



    Rs 14,900.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 3 Pole (100 Amp)

    0 out of 5



    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    3P
    number of protected poles
    3
    [In] rated current
    100 A
    network type
    AC
    DC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Manual tripping test
    Toggle
    local signalling
    ON/OFF indication
    Trip indicator
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    9
    height
    103mm
    width
    81mm
    depth
    81mm
    net weight
    0.72kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 47,000.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 3 Pole (125 Amp)

    0 out of 5



    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    3P
    number of protected poles
    3
    [In] rated current
    125 A
    network type
    DC
    AC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Manual tripping test
    Toggle
    local signalling
    ON/OFF indication
    Trip indicator
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    9
    height
    103mm
    width
    81mm
    depth
    81mm
    net weight
    0.72kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 48,000.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 3 Pole (80 Amp)

    0 out of 5



    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    3P
    number of protected poles
    3
    [In] rated current
    80 A
    network type
    DC
    AC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Toggle
    Manual tripping test
    local signalling
    ON/OFF indication
    Trip indicator
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    9
    height
    103mm
    width
    81mm
    depth
    81mm
    net weight
    0.72kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 46,000.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 4 Pole (100 Amp)

    0 out of 5



    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    4P
    number of protected poles
    4
    [In] rated current
    100 A
    network type
    AC
    DC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Manual tripping test
    Toggle
    local signalling
    ON/OFF indication
    Trip indicator
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    12
    height
    103mm
    width
    108mm
    depth
    81mm
    net weight
    0.96kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 56,000.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 4 Pole (125 Amp)

    0 out of 5
    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    4P
    number of protected poles
    4
    [In] rated current
    125 A
    network type
    DC
    AC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Toggle
    Manual tripping test
    local signalling
    ON/OFF indication
    Trip indicator
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    12
    height
    103mm
    width
    108mm
    depth
    81mm
    net weight
    0.96kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 60,000.00
  • Schneider (NG125A) High Performance Miniature Circuit Breaker 4 Pole (80 Amp)

    0 out of 5



    range of product
    NG125
    range
    Acti 9
    product name
    Acti 9 NG125
    product or component type
    Miniature circuit-breaker
    device short name
    NG125a
    device application
    Distribution
    poles description
    4P
    number of protected poles
    4
    [In] rated current
    80 A
    network type
    AC
    DC
    trip unit technology
    Thermal-magnetic
    curve code
    C
    network frequency
    50/60 Hz
    contact position indicator
    Yes
    control type
    Manual tripping test
    Toggle
    local signalling
    Trip indicator
    ON/OFF indication
    mounting mode
    Clip-on
    mounting support
    35 mm symmetrical DIN rail
    comb busbar and distribution block compatibility
    NO
    9 mm pitches
    12
    height
    103mm
    width
    108mm
    depth
    81mm
    net weight
    0.96kg
    mechanical durability
    20000cycles
    electrical durability
    5000cycles



    Rs 54,000.00
  • Schneider (NG125LMA) Motor Starter Protection Breaker 2 Pole (MA curve)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 4 Amp
    • 10 Amp
    • 16 Amp
    • 25 Amp
    • 40 Amp
    • 63 Amp
    • 80 Amp
    Rs 15,500.00
  • Schneider (NG125LMA) Motor Starter Protection Breaker 3 Pole (MA curve)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 4 Amp
    • 10 Amp
    • 16 Amp
    • 25 Amp
    • 40 Amp
    • 63 Amp
    • 80 Amp
    Rs 34,000.00
  • Schneider (P25M) Motor Protection Circuit Breaker 3 pole

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 0.16 Amp
    • 0.25 Amp
    • 0.4 Amp
    • 0.63 Amp
    • 1 Amp
    • 1.6 Amp
    • 2.5 Amp
    • 4 Amp
    • 6.3 Amp
    • 10 Amp
    • 14 Amp
    • 18 Amp
    • 23 Amp
    • 25 Amp
    Rs 13,500.00
  • Schneider Battery Control Module for SMPS Power Supply (ABL8BBU24200) Input 24-28.8 VDC Out 20 Amp

    0 out of 5

    Model:ABL8BBU24200

    product or component type
    Battery control module
    input voltage
    24…28.8 V DC
    output voltage
    (Ubattery-0.5) V in battery mode DC
    (Uin-0.25) V in nominal mode DC
    maximum output current
    20A
    input voltage limits
    22…30 V
    maximum power dissipation in W
    7W
    activation threshold
    Adjustable 22…36 V
    number of output channels
    1
    current consumption
    0.6 A on load
    0.1 mA no load
    <= 40.6 A
    output protection type
    Against overload, protection technology: 1.5 x In
    Against short-circuits, protection technology: battery-backed mode, automatic reset
    Against short-circuits, protection technology: power-supplied mode
    connections – terminals
    For diagnostic relay: removable screw terminal block, connection capacity: 1 x 0.75 mm
    For input connection: screw type terminals, connection capacity: 2 x 0.5…2 x 10 mm AWG 20…AWG 8
    For output connection: screw type terminals, connection capacity: 2 x 0.5…2 x 10 mm AWG 20…AWG 8
    fixing mode
    By clips on 35 mm symmetrical DIN rail, operating position: horizontal
    By clips on 35 mm symmetrical DIN rail, operating position: vertical
    operating altitude
    2000 m
    marking
    CE
    name of test
    Electrostatic discharges conforming to EN/IEC 61000-4-2
    Emission conforming to EN 61000-6-3
    Induced electromagnetic field conforming to EN/IEC 61000-4-6 level 3
    Radiated electromagnetic field conforming to EN/IEC 61000-4-3 level 3
    Rapid transient conforming to IEC 61000-4-4 level 3
    Surge conforming to EN/IEC 61000-4-5 level 2
    Conducted/radiated emissions conforming to EN 55022 class B, 20 %
    local signalling
    1 C/O relayalarm status:
    1 C/O relaybattery status:
    1 C/O relaypower supply status:
    LCD screenmodule status:
    width
    60mm
    height
    125mm
    depth
    160mm
    net weight
    0.5kg



    Rs 48,000.00
  • Schneider C120N Circuit Breaker 1 pole B-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 80 Amp
    • 100 Amp
    • 125 Amp
    Rs 4,800.00
  • Schneider C120N Circuit Breaker 2 pole B-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 80 Amp
    • 100 Amp
    • 125 Amp
    Rs 10,200.00
  • Schneider C120N Circuit Breaker 3 pole B-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 80 Amp
    • 100 Amp
    • 125 Amp
    Rs 11,000.00
  • Schneider C120N Circuit Breaker 4 pole B-curve

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 80 Amp
    • 100 Amp
    • 125 Amp
    Rs 18,000.00
  • Schneider EasyPact (CAE31U5) 3NO + 1NC Control Relay 240 VAC

    0 out of 5

    Model: CAE31U5

    range
    EasyPact
    product name
    EasyPact TVS
    product or component type
    Control relay
    device short name
    CAE
    contactor application
    Control circuit
    colour
    Grey (RAL 7011)
    utilisation category
    AC-14
    AC-15
    pole contact composition
    3 NO + 1 NC
    [Ue] rated operational voltage
    <= 690 V AC
    control circuit type
    AC at 50 Hz
    [Uc] control circuit voltage
    240 V AC 50 Hz
    [Uimp] rated impulse withstand voltage
    6kV conforming to IEC 60947
    [Ith] conventional free air thermal current
    10A (at 40C)
    Irms rated making capacity
    140A at 690 V AC conforming to IEC 60947-5-1
    [Icw] rated short-time withstand current
    120A – 500 ms
    140A – 100 ms
    associated fuse rating
    10A gG at 690 V conforming to IEC 60947-5-1
    [Ui] rated insulation voltage
    690V conforming to IEC 60947-5-1
    mounting support
    Plate
    Rail
    connections – terminals
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible without cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: flexible with cable end
    Screw clamp terminals 1 12.5mm – cable stiffness: solid without cable end
    Screw clamp terminals 2 12.5mm – cable stiffness: solid without cable end
    tightening torque
    1.2N.m – on screw clamp terminals – with screwdriver Philips No 2
    control circuit voltage limits
    Operational: 0.85…1.1 Uc at 50 Hz
    Drop-out: 0.3…0.6 Uc
    operating time
    4…19 ms coil energisation and NC opening
    12…22 ms coil energisation and NO closing
    4…12 ms coil de-energisation and NC opening
    6…17 ms coil de-energisation and NO closing
    mechanical durability
    10Mcycles
    maximum operating rate
    180cyc/mn
    inrush power in VA
    70VA 50 Hz (at 20C)
    hold-in power consumption in VA
    8VA 50 Hz (at 20C)
    minimum switching voltage
    17V
    minimum switching current
    5mA
    non-overlap time
    1.5ms on energisation between NC and NO contact
    1.5ms on de-energisation between NC and NO contact
    insulation resistance
    > 10 MOhm
    mechanical robustness
    Shocks control relay open: 7 Gn for 11 ms
    Shocks control relay closed: 10 Gn for 11 ms
    Vibrations control relay open: 1.5 Gn, 5…300 Hz
    Vibrations control relay closed: 3 Gn, 5…300 Hz
    height
    74mm
    width
    45mm
    depth
    80mm
    net weight
    0.28kg



    Rs 3,200.00
  • Schneider Easypact Molded-case circuit breaker (EZC100B) 3 Pole TMD

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 15 Amp
    • 20 Amp
    • 30 Amp
    • 40 Amp
    • 50 Amp
    • 60 Amp
    Rs 8,500.00
  • Schneider Easypact Molded-case circuit breaker (EZC100F) 3 Pole TMD

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 15 Amp
    • 20 Amp
    • 30 Amp
    • 40 Amp
    • 50 Amp
    • 60 Amp
    • 75 Amp
    • 80 Amp
    • 100 Amp
    Rs 8,500.00
  • Schneider Easypact Molded-case Circuit Breaker (EZC100H) TMD (4 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 15 Amp
    • 20 Amp
    • 30 Amp
    • 40 Amp
    • 50 Amp
    • 60 Amp
    • 75 Amp
    • 80 Amp
    • 100 Amp
    Rs 11,500.00
  • Schneider Easypact Molded-case Circuit Breaker (EZC100H) TMD 1 Pole

    0 out of 5

    Available ampere (must write any one in adittional information/order notes)

    • 15 Amp
    • 20 Amp
    • 30 Amp
    • 40 Amp
    • 50 Amp
    • 60 Amp
    • 75 Amp
    • 80 Amp
    • 100 Amp
    Rs 2,800.00
  • Schneider Easypact Molded-case Circuit Breaker (EZC100H) TMD 2 Pole

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 15 Amp
    • 20 Amp
    • 30 Amp
    • 40 Amp
    • 50 Amp
    • 60 Amp
    • 75 Amp
    • 80 Amp
    • 100 Amp
    Rs 3,900.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZC250N) TMD (3 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 125 Amp
    • 150 Amp
    • 175 Amp
    • 200 Amp
    • 225 Amp
    • 250 Amp
    Rs 27,800.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZC250N) TMD (4 Pole)

    0 out of 5

    Available ampere (must write in additional information/order notes)

    • 125 Amp
    • 150 Amp
    • 175 Amp
    • 200 Amp
    • 225 Amp
    • 250 Amp
    Rs 22,500.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZC400N) TMD (3 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 320 Amp
    • 400 Amp
    Rs 59,000.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZC630H) TMD (4 Pole) 400 Amp

    0 out of 5



    range of product
    EasyPact
    product or component type
    Circuit breaker
    device short name
    Easypact EZC630H
    circuit breaker name
    Easypact EZC630H
    device application
    Distribution
    poles description
    4P
    protected poles description
    4t
    network type AC
    network frequency
    50/60 Hz
    [In] rated current 400 ampere
    control type
    Toggle
    mounting mode
    Fixed
    mounting support
    Backplate
    upside connection
    Front
    downside connection
    Front
    mechanical durability
    10000 cycles
    electrical durability
    5000 cycles
    protection type
    Overload protection
    Short-circuit protection



    Rs 92,000.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZC630N) TMD (3 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 500 Amp
    • 600 Amp
    Rs 72,000.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZCV250N) TMD (3 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 100 Amp
    • 125 Amp
    • 150 Amp
    • 160 Amp
    • 175 Amp
    • 200 Amp
    • 225 Amp
    • 250 Amp
    Rs 19,000.00
  • Schneider Easypact Molded-Case Circuit Breaker (EZCV250N) TMD (4 Pole)

    0 out of 5

    Available ampere (must write any one in additional information/order notes)

    • 100 Amp
    • 125 Amp
    • 150 Amp
    • 160 Amp
    • 175 Amp
    • 200 Amp
    • 225 Amp
    • 250 Amp
    Rs 25,300.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS100B) 25 kA TM-D (3 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information order/notes)

    • 11.2 – 16 Amp
    • 17.5 – 25 Amp
    • 22.4 – 32 Amp
    • 28 – 40 Amp
    • 35 – 50 Amp
    • 44.1 – 63 Amp
    • 56 – 80 Amp
    • 70 – 100 Amp
    Rs 19,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS100B) 25 kA TM-D (4 Pole)

    0 out of 5

    Adjustable ampere range (must write any one in additional in formation/order notes)

    • 11.2 – 16 Amp
    • 17.5 – 25 Amp
    • 22.4 – 32 Amp
    • 28 – 40 Amp
    • 35 – 50 Amp
    • 44.1 – 63 Amp
    • 56 – 80 Amp
    • 70 – 100 Amp
    Rs 22,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS100F) 36 kA TM-D (3 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 11.2-16 Amp
    • 17.5-25 Amp
    • 22.4-32 Amp
    • 28-40 Amp
    • 35-50 Amp
    • 44.1-63 Amp
    • 56-80 Amp
    • 70-100 Amp
    Rs 18,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS100F) 36 kA TM-D (4 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 11.2-16 Amp
    • 17.5-25 Amp
    • 22.4-32 Amp
    • 28-40 Amp
    • 35-40 Amp
    • 44.1-63 Amp
    • 56-80 Amp
    • 70-100 Amp
    Rs 27,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS160B) 25 kA TM-D (3 Pole)

    0 out of 5

    Adjustable ampere range (must write any one in additional information order/notes)

    • 87.5 – 125 Amp
    • 112 – 160 Amp
    Rs 33,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS160B) 25 kA TM-D (4 Pole)

    0 out of 5

    Available ampere range (must write any one in additional information/order notes)

    • 87.5-125 Amp
    • 112-160 Amp
    Rs 43,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS250F) 36 kA TM-D (3 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 140-200 Amp
    • 175-250 Amp
    Rs 52,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS250F) 36 kA TM-D (4 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 140 – 200 Amp
    • 175 – 250 Amp
    Rs 55,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS400F) 36 kA TM-D (3 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 224 – 320 Amp
    • 280 – 400 Amp
    Rs 95,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS400F) 36 kA TM-D (4 Pole)

    0 out of 5

    Adjustable available ampere (must write any one in additional information/order notes)

    • 224 – 320 Amp
    • 280 – 400 Amp
    Rs 109,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS400N) 50 kA TM-D (3 Pole)

    0 out of 5

    These Adjustable ampere available (must write any one in additional information/order notes)

    • 224 – 320 Amp
    • 280 – 400 Amp
    Rs 105,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS400N) 50 kA TM-D (4 Pole)

    0 out of 5

    These adjustable ampere available (must write any one in additional information/order notes)

    • 224 – 320 Amp
    • 280 – 400 Amp
    Rs 130,000.00
  • Schneider Easypact Molded-Case Circuit Breaker Adjustable (CVS630F) 36 kA TM-D (3 Pole)

    0 out of 5

    These adjustable ampere available (must write any one in additional information/order notes)

    • 350 – 500 Amp
    • 420 – 600 Amp
    Rs 119,000.00
  • Schneider IC60L Miniature Circuit Breaker 2 pole

    0 out of 5

    Available ampere range (must write any one in additional information/order notes)

    • 6 Amp
    • 10 Amp
    • 16 Amp
    • 20 Amp
    • 32 Amp
    • 40 Amp
    • 50 Amp
    • 63 Amp
    Rs 4,900.00
  • Schneider IC60L Miniature Circuit Breaker 3 pole

    0 out of 5

    Available ampere range (must write any one in additional information/order notes)

    • 6 Amp
    • 10 Amp
    • 16 Amp
    • 20 Amp
    • 32 Amp
    • 40 Amp
    • 50 Amp
    • 63 Amp
    Rs 6,900.00
  • Schneider Magnetic Contactor 3 pole (LC1D09) 9 Amp

    0 out of 5

    Available in these voltages (must write any one in additional information order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 3,000.00
  • Schneider Multi 9 Residual Current Circuit Breaker 2 Pole 25A (A9N16234) 30mA

    0 out of 5

    Model: A9N16234

    range
    Multi 9
    product name
    Multi 9 ID
    product or component type
    Residual current circuit breaker (RCCB)
    device short name
    ID
    device application
    Distribution
    poles description
    2P
    neutral position
    Left
    [In] rated current
    25A
    network type
    AC
    earth-leakage sensitivity
    30mA
    earth-leakage protection time delay
    Instantaneous
    earth-leakage protection class
    Type AC
    network frequency
    50 Hz
    [Ue] rated operational voltage
    220…240 V AC 50 Hz
    residual current tripping technology
    Voltage independent
    rated breaking and making capacity
    Idm 250A conforming to EN/IEC 61008-1
    rated conditional short-circuit current
    Inc 10kA
    [Ui] rated insulation voltage
    440V AC 50 Hz conforming to EN/IEC 61008-1
    [Uimp] rated impulse withstand voltage
    6kV conforming to EN/IEC 61008-1
    surge current
    250A
    contact position indicator
    Yes
    control type
    Toggle
    local signalling
    ON, OFF, fault trip
    mounting mode
    Clip-on
    mounting support
    DIN rail
    9 mm pitches
    4
    height
    81mm
    width
    36mm
    depth
    73mm
    net weight
    0.23kg
    colour wheit
    mechanical durability
    20000cycles
    electrical durability
    2000cycles



    Rs 8,900.00
  • Schneider Multi 9 Residual Current Circuit Breaker 4 Pole 40A (A9N16324) 30mA

    0 out of 5

    Model: A9N16324

    range
    Multi 9
    product name
    Multi 9 ID
    product or component type
    Residual current circuit breaker (RCCB)
    device short name
    ID
    device application
    Distribution
    poles description
    4P
    neutral position
    Left
    Line Rated Current
    40A
    network type
    AC
    earth-leakage sensitivity
    30mA
    earth-leakage protection time delay
    Instantaneous
    earth-leakage protection class
    Type AC
    network frequency
    50 Hz
    [Ue] rated operational voltage
    380…415 V AC 50 Hz
    residual current tripping technology
    Voltage independent
    rated breaking and making capacity
    Idm 400A EN/IEC 61008-1
    rated conditional short-circuit current
    Inc 10kA
    [Ui] rated insulation voltage
    440V AC 50 Hz EN/IEC 61008-1
    [Uimp] rated impulse withstand voltage
    6kVEN/IEC 61008-1
    surge current
    250A
    contact position indicator
    Yes
    control type
    Toggle
    local signalling
    ON, OFF, fault trip
    mounting mode
    Clip-on
    mounting support
    DIN rail
    9 mm pitches
    8
    height
    3.19in (81mm)
    width
    2.83in (72mm)
    depth
    2.87in (73mm)
    net weight
    0.99lb(US) (0.45kg)
    color wheit
    mechanical durability
    20000cycles
    electrical durability
    2000cycles



    Rs 22,900.00
  • Schneider Residual Current Circuit Breaker 2 Pole 40A (A9N16237) 30mA

    0 out of 5

    Model: A9N16237

    range
    Acti 9
    product name
    Acti 9 xID
    product or component type
    Residual current circuit breaker (RCCB)
    device short name
    XID
    poles description
    2P
    neutral position
    Left
    [In] rated current
    40A
    network type
    AC
    earth-leakage sensitivity
    30mA
    earth-leakage protection time delay
    Instantaneous
    earth-leakage protection class
    Type A-SI
    rated breaking and making capacity
    500A conforming to EN/IEC 61008-1
    suitability for isolation
    Yes
    network frequency
    50 Hz
    [Ue] rated operational voltage
    230…240 V AC 50 Hz
    [Ui] rated insulation voltage
    500V AC 50 Hz
    [Uimp] rated impulse withstand voltage
    6kV
    contact position indicator
    Yes
    control type
    Toggle
    local signalling
    ON, OFF, fault trip
    mounting mode
    Clip-on
    mounting support
    DIN rail
    comb busbar and distribution block compatibility
    Downside: biconnect
    9 mm pitches
    4
    height
    81mm
    width
    36mm
    depth
    75mm
    net weight
    210g
    colour
    White
    mechanical durability
    4000cycles
    electrical durability
    4000cycles
    Rs 5,900.00
  • Schneider Residual Current Circuit Breaker 4 Pole 125A (16905) 30mA

    0 out of 5

    Model: 16905

    range
    Acti 9
    product name
    Acti 9 RCCB-ID
    product or component type
    Residual current circuit breaker (RCCB)
    device short name
    RCCB-ID
    poles description
    4P
    neutral position
    Left
    [In] rated current
    125A
    network type
    AC
    earth-leakage sensitivity
    30mA
    earth-leakage protection time delay
    Instantaneous
    earth-leakage protection class
    Type AC
    rated breaking and making capacity
    Im = 1250A 400 V conforming to IEC 61008
    rated conditional short-circuit current
    Inc 10kA 125A
    evice location in system
    Outgoer
    network frequency
    50/60 Hz
    [Ue] rated operational voltage
    400 V AC 50 Hz conforming to IEC 61008
    residual current tripping technology
    Electromechanical
    [Ui] rated insulation voltage
    440V AC 50 Hz conforming to IEC 61008-1
    [Uimp] rated impulse withstand voltage
    4kV conforming to IEC 61008-1
    control type
    Toggle
    mounting mode
    Fixed
    mounting support
    35 mm symmetrical DIN rail
    9 mm pitches
    8
    height
    86mm
    width
    72mm
    depth
    76mm
    net weight
    420g
    colour wheit
    mechanical durability
    5000cycles
    electrical durability
    2000cycles



    Rs 32,900.00
  • Schneider Switching Mode Power Supply (ABL1REM12050) In 100~240 VAC, Out 12 VDC, 60 W 5 Amp

    0 out of 5

    Model:ABL1REM12050

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    60W
    input voltage
    100…240 V AC single phase
    120…370 V DC
    output voltage
    12 V DC
    power supply output current
    5A
    operating position
    Any position
    vibration resistance
    2 gn (f= 9150Hz) conforming to EN/IEC 61131-2
    3.5 mm (f= 59Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-4-8 level 4
    Electrostatic discharges conforming to EN/IEC 61000-4-2 level 3
    Induced electromagnetic field conforming to EN/IEC 61000-4-6 level 3
    Radiated electromagnetic field conforming to EN/IEC 61000-4-3 level 3
    Rapid transient conforming to IEC 61000-4-4 level 3
    Conducted/radiated emissions conforming to EN 55022 class B
    Conducted/radiated emissions conforming to EN/IEC 55011
    Emission conforming to EN/IEC 61000-6-3
    Primary outage conforming to IEC 61000-4-11
    Surge conforming to EN/IEC 61000-4-5
    input voltage limits
    85…264 V
    network frequency
    47…63 Hz
    inrush current
    50A at 115 V AC
    100A at 230 V AC
    cos phi
    0.65
    efficiency
    80%
    power dissipation in W
    15W
    current consumption
    1 A at 240 V
    2 A at 100 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    10.8…13.2 V
    line and load regulation
    +/- 3 %
    holding time
    >= 10 ms at 100 V
    >= 40 ms at 240 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: tripping if U > 1.25 x Un
    Against short-circuits, protection technology: automatic reset
    Thermal
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    For input connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    For output connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    marking
    CE
    mounting support
    Panel
    Reversible mounting bracket
    operating altitude
    2000 m
    output coupling
    Series
    Parallel
    overvoltage category
    II
    meantime between failure [MTBF]
    100000h at 40C
    status LED
    1 LED (green)output voltage:
    net weight
    0.44kg



    Rs 12,000.00
  • Schneider Switching Mode Power Supply (ABL1REM24025) In 100~240 VAC, Out 24 VDC, 60 W 2.5 Amp

    0 out of 5

    Model:ABL1REM24025

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    60W
    input voltage 100…240 V AC single phase
    output voltage
    24 V DC
    power supply output current
    2.5A
    operating position
    Any position
    vibration resistance
    2 gn (f= 9150Hz) conforming to EN/IEC 61131-2
    3.5 mm (f= 59Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-4-8 level 4
    Electrostatic discharges conforming to EN/IEC 61000-4-2 level 3
    Induced electromagnetic field conforming to EN/IEC 61000-4-6 level 3
    Radiated electromagnetic field conforming to EN/IEC 61000-4-3 level 3
    Rapid transient conforming to IEC 61000-4-4 level 3
    Conducted/radiated emissions conforming to EN 55022 class B
    Conducted/radiated emissions conforming to EN/IEC 55011
    Emission conforming to EN/IEC 61000-6-3
    Primary outage conforming to IEC 61000-4-11
    Surge conforming to EN/IEC 61000-4-5
    input voltage limits
    85…264 V
    network frequency
    47…63 Hz
    inrush current
    50A at 115 V AC
    100A at 230 V AC
    cos phi
    0.65
    efficiency
    80%
    power dissipation in W
    15W
    current consumption
    1 A at 240 V
    2 A at 100 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 3 %
    holding time
    >= 10 ms at 100 V
    >= 40 ms at 240 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: tripping if U > 1.25 x Un
    Against short-circuits, protection technology: automatic reset
    Thermal
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    For input connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    For output connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    marking
    CE
    mounting support
    Reversible mounting bracket
    Panel
    operating altitude
    2000 m
    output coupling
    Parallel
    Series
    overvoltage category
    II
    meantime between failure [MTBF]
    100000h at 40C
    status LED
    1 LED (green)output voltage:
    net weight
    0.44kg



    Rs 8,900.00
  • Schneider Switching Mode Power Supply (ABL1REM24100) In 100~240 VAC, Out 24 VDC, 240 W 10 Amp

    0 out of 5

    Model:ABL1REM24100

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    240W
    input voltage
    100…120 V AC single phase
    200…240 V AC single phase
    180…370 V DC
    output voltage
    24 V DC
    power supply output current
    10A
    operating position
    Any position
    vibration resistance
    2 gn (f= 9150Hz) conforming to EN/IEC 61131-2
    3.5 mm (f= 59Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-4-8 level 4
    Electrostatic discharges conforming to EN/IEC 61000-4-2 level 3
    Induced electromagnetic field conforming to EN/IEC 61000-4-6 level 3
    Radiated electromagnetic field conforming to EN/IEC 61000-4-3 level 3
    Rapid transient conforming to IEC 61000-4-4 level 3
    Conducted/radiated emissions conforming to EN 55022 class B
    Conducted/radiated emissions conforming to EN/IEC 55011
    Emission conforming to EN/IEC 61000-6-3
    Primary outage conforming to IEC 61000-4-11
    Surge conforming to EN/IEC 61000-4-5
    input voltage limits
    170…264 V
    85…132 V
    network frequency
    47…63 Hz
    inrush current
    50A at 115 V AC
    100A at 230 V AC
    cos phi
    0.65
    efficiency
    80%
    power dissipation in W
    60W
    current consumption
    3 A at 240 V
    6 A at 100 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 3 %
    holding time
    >= 10 ms at 100 V
    >= 40 ms at 240 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: tripping if U > 1.25 x Un
    Against short-circuits, protection technology: automatic reset
    Thermal
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    For input connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    For output connection: screw type terminals, connection capacity: 4 x 4 mm AWG 12
    marking
    CE
    mounting support
    Reversible mounting bracket
    Panel
    operating altitude
    2000 m
    output coupling
    Series
    Parallel
    overvoltage category
    II
    meantime between failure [MTBF]
    100000h at 40C
    status LED
    1 LED (green)output voltage:
    net weight
    0.88kg



    Rs 22,000.00
  • Schneider Switching Mode Power Supply (ABL1RPM24100) In 100~240 VAC, Out 24 VDC, 240 W 10 Amp

    0 out of 5

    Model: ABL1RPM24100

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    240W
    input voltage
    180…370 V DC
    100…240 V AC single phase
    output voltage
    24 V DC
    power supply output current
    10A
    operating position
    Any position
    vibration resistance
    2 gn (f= 9150Hz) conforming to EN/IEC 61131-2
    3.5 mm (f= 59Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-4-8 level 4
    Electrostatic discharges conforming to EN/IEC 61000-4-2 level 3
    Induced electromagnetic field conforming to EN/IEC 61000-4-6 level 3
    Radiated electromagnetic field conforming to EN/IEC 61000-4-3 level 3
    Rapid transient conforming to IEC 61000-4-4 level 3
    Conducted/radiated emissions conforming to EN 55022 class B
    Conducted/radiated emissions conforming to EN/IEC 55011
    Emission conforming to EN/IEC 61000-6-3
    Primary outage conforming to IEC 61000-4-11
    Surge conforming to EN/IEC 61000-4-5
    input voltage limits
    85…132 V
    170…264 V
    network frequency
    47…63 Hz
    inrush current
    50A at 115 V AC
    100A at 230 V AC
    cos phi
    0.70.95
    efficiency
    80%
    power dissipation in W
    60W
    current consumption
    3 A at 240 V
    6 A at 100 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 3 %
    holding time
    >= 10 ms at 100 V
    >= 40 ms at 240 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: tripping if U > 1.25 x Un
    Against short-circuits, protection technology: automatic reset
    Thermal
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    For input connection: screw type terminals, connection capacity: 2 x 4 mm AWG 12
    For output connection: screw type terminals, connection capacity: 4 x 4 mm AWG 12
    marking
    CE
    mounting support
    Reversible mounting bracket
    Panel
    operating altitude
    2000 m
    output coupling
    Parallel
    Series
    overvoltage category
    II
    meantime between failure [MTBF]
    100000h at 40C
    status LED
    1 LED (green)output voltage:
    net weight
    1.23kg



    Rs 18,900.00
  • Schneider Switching Mode Power Supply (ABL2REM24045H) In 100~240 VAC, Out 24 VDC, 100 W 4.5 Amp

    0 out of 5

    Model: ABL2REM24045H

    range of product
    Easy Modicon ABL2
    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    100W
    input voltage
    100…240 V AC single phase
    output voltage
    24 V DC
    power supply output current
    4.5A
    operating position
    Any position
    vibration resistance
    2 gn (f= 10500Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-6-4 level A
    input voltage limits
    85…264 V
    network frequency
    47…63 Hz
    inrush current
    50A at 100…240 V AC
    cos phi
    0.45
    efficiency
    83%
    power dissipation in W
    11.1W
    current consumption
    1.1 A at 240 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 1 %
    holding time
    >= 10 ms at 115 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against short-circuits, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: 1.1…1.5 x In
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    marking
    CE
    mounting support
    DIN rail with accessory
    Panel mounting with accessory
    operating altitude
    2000 m
    output coupling
    Series
    overvoltage category
    II
    meantime between failure [MTBF]
    350000h at 25C
    status LED
    1 LED (green)output voltage:
    width
    97mm
    height
    164mm
    depth
    38mm
    net weight
    0.58kg



    Rs 15,500.00
  • Schneider Switching Mode Power Supply (ABL2REM24085H) In 100~240 VAC, Out 24 VDC, 200 W 8.3 Amp

    0 out of 5

    Model: ABL2REM24085H

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    200W
    input voltage
    100…120 V AC single phase
    200…240 V
    output voltage
    24 V DC
    power supply output current
    8.3A
    operating position
    Any position
    vibration resistance
    2 gn (f= 10500Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-6-4 level A
    input voltage limits
    85…264 V
    90…132 V
    network frequency
    47…63 Hz
    inrush current
    60A at 100…120 V AC
    60A at 200…240 V AC
    cos phi
    0.5
    efficiency
    83%
    power dissipation in W
    27.2W
    current consumption
    2 A at 240 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 1 %
    holding time
    >= 12 ms at 115 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against short-circuits, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: 1.1…1.5 x In
    Thermal, protection technology: 1.1…1.5 x In
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    marking
    CE
    mounting support
    DIN rail with accessory
    Panel mounting with accessory
    operating altitude
    2000 m
    output coupling
    Series
    overvoltage category
    II
    meantime between failure [MTBF]
    350000h at 25C
    status LED
    1 LED (green)output voltage:
    width
    115mm
    height
    215mm
    depth
    50mm
    net weight
    0.97kg



    Rs 19,000.00
  • Schneider Switching Mode Power Supply (ABL2REM24150H) In 100~240 VAC, Out 24 VDC, 350 W 14,6 Amp

    0 out of 5



    range of product
    Easy Modicon ABL2
    product or component type
    Power supply
    power supply type
    Regulated switch mode
    rated power in W
    350W
    input voltage
    100…120 V AC single phase
    200…240 V
    output voltage
    24 V DC
    power supply output current
    14.6A
    operating position
    Any position
    vibration resistance
    2 gn (f= 10500Hz) conforming to EN/IEC 61131-2
    name of test
    Conducted interference conforming to EN 61000-6-4 level A
    Complementary
    input voltage limits
    85…264 V
    180…264 V
    network frequency
    47…63 Hz
    inrush current
    60A at 100…120 V AC
    60A at 200…240 V AC
    cos phi
    0.5
    efficiency
    83%
    power dissipation in W
    47.7W
    current consumption
    3.3 A at 240 V
    input protection type
    Integrated fuse (not interchangeable)
    output voltage limits
    21.6…26.4 V
    line and load regulation
    +/- 1 %
    holding time
    >= 12 ms at 115 V
    output protection type
    Against overload, protection technology: 1.1…1.5 x In
    Against short-circuits, protection technology: 1.1…1.5 x In
    Against overvoltage, protection technology: 1.1…1.5 x In
    Thermal, protection technology: 1.1…1.5 x In
    connections – terminals
    For ground connection: screw type terminals, connection capacity: 1 x 4 mm AWG 12
    marking
    CE
    mounting support
    DIN rail with accessory
    Panel mounting with accessory
    operating altitude
    2000 m
    output coupling
    Series
    overvoltage category
    II
    meantime between failure [MTBF]
    350000h at 25C
    status LED
    1 LED (green)output voltage:
    width
    115mm
    height
    215mm
    depth
    50mm
    net weight
    0.97kg
    Environment
    product certifications
    EAC
    IC
    RoHS
    environmental characteristic
    EMC conforming to EN 55022 class B
    IP degree of protection
    IP20 conforming to EN/IEC 60950
    ambient air temperature for operation
    -2070C (with rated power derating 5 W per C)
    ambient air temperature for storage
    -2085C
    relative humidity
    2090%
    overvoltage category
    Class I conforming to VDE 0106-1
    pollution degree
    2
    dielectric strength
    2000V between input and ground
    Offer Sustainability
    REACh Regulation
    REACh Declaration
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Pro-active compliance (Product out of EU RoHS legal scope)
    EU RoHS Declaration
    Mercury free
    Yes
    RoHS exemption information
    Yes
    China RoHS Regulation
    China RoHS declaration



    Rs 14,000.00
  • Schneider Switching Mode Power Supply (ABL8REM24050) In 100~240 VAC, Out 24 VDC, 5 Amp

    0 out of 5

    Model: ABL8REM24050

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…240 V AC phase to phase, terminal(s): L1-L2
    100…240 V AC single phase, terminal(s): N-L1
    110…220 V DC
    rated power in W
    120W
    output voltage
    24 V DC
    power supply output current
    5A
    Power Factor
    0.65
    efficiency
    85%
    Output voltage adjustment
    100…120 % adjustable
    power dissipation in W
    21.2W
    current consumption
    1.2 A at 240 V
    1.9 A at 100 V
    Hold-up time
    >= 10 ms at 100 V
    >= 10 ms at 240 V
    connections – terminals
    For input connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    For output connection: screw type terminals, connection capacity: 4 x 0.14…4 x 2.5 mm AWG 26…AWG 14
    For input ground connection: screw type terminals, connection capacity: 1 x 0.14…1 x 2.5 mm AWG 26…AWG 14
    For output ground connection: screw type terminals, connection capacity: 2 x 0.14…2 x 2.5 mm AWG 26…AWG 14
    status LED
    1 LED (green)output voltage:
    1 LED (orange)input voltage:
    depth
    120mm
    height
    120mm
    width
    54mm
    net weight
    1kg
    output coupling
    Series
    Parallel
    marking
    CE
    operating position
    Vertical



    Rs 25,900.00
  • Schneider Switching Mode Power Supply (ABL8RPM24200) In 100~240 VAC, Out 24 VDC, 20 Amp

    0 out of 5

    Model: ABL8RPM24200

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…120 V AC single phase, terminal(s): N-L1
    200…240 V AC phase to phase, terminal(s): L1-L2
    rated power in W
    480W
    output voltage
    24 V DC
    power supply output current
    20A
    permissible temporary current boost
    1.5 x In (for 4 s)
    Power Factor
    0.68 at 240 V
    0.69 at 120 V
    efficiency
    88%
    Output voltage adjustment
    24…28.8 V adjustable
    power dissipation in W
    57.6W
    Hold-up time
    >= 120 ms at 400 V
    >= 20 ms at 100 V
    >= 40 ms at 240 V
    provided equipment
    Power factor correction filter conforming to IEC 61000-3-2
    connections – terminals
    For diagnostic relay: removable screw terminal block, connection capacity: 2 x 2.5 mm
    For input connection: screw type terminals, connection capacity: 3 x 0.5…3 x 4 mm AWG 22…AWG 12
    For input ground connection: screw type terminals, connection capacity: 1 x 0.5…1 x 4 mm AWG 22…AWG 12
    For output connection: screw type terminals, connection capacity: 4 x 0.5…4 x 4 mm AWG 22…AWG 12
    status LED
    1 LED (green and red)output voltage:
    1 LED (green, red and orange)output current:
    depth
    145mm
    height
    125mm
    width
    146mm
    net weight
    1.6kg



    Rs 99,000.00
  • Schneider Switching Mode Power Supply (ABL8RPS24050) In 100~500 VAC, Out 24 VDC, 5 Amp

    0 out of 5

    Model:ABL8RPS24050

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    100…120 V AC single phase, terminal(s): N-L1
    200…500 V AC phase to phase, terminal(s): L1-L2
    rated power in W
    120W
    output voltage
    24 V DC
    power supply output current
    5A
    permissible temporary current boost
    1.5 x In (for 4 s)
    Power Factor
    0.51 at 240 V
    0.59 at 120 V
    efficiency
    87%
    Output voltage adjustment
    24…28.8 V adjustable
    power dissipation in W
    15.5W
    Hold-up time
    >= 120 ms at 400 V
    >= 20 ms at 100 V
    >= 40 ms at 240 V
    provided equipment
    Power factor correction filter conforming to IEC 61000-3-2
    connections – terminals
    For diagnostic relay: removable screw terminal block, connection capacity: 2 x 2.5 mm
    For input connection: screw type terminals, connection capacity: 3 x 0.5…3 x 4 mm AWG 22…AWG 12
    For input ground connection: screw type terminals, connection capacity: 1 x 0.5…1 x 4 mm AWG 22…AWG 12
    For output connection: screw type terminals, connection capacity: 4 x 0.5…4 x 4 mm AWG 22…AWG 12
    For output ground connection: screw type terminals, connection capacity: 1 x 0.5…1 x 4 mm AWG 22…AWG 12
    status LED
    1 LED (green and red)output voltage:
    1 LED (green, red and orange)output current:
    depth
    125mm
    height
    143mm
    width
    56mm
    net weight
    0.7kg
    output coupling
    Parallel
    Series
    marking
    CE
    operating position
    Vertical



    Rs 39,000.00
  • Schneider Switching Mode Power Supply (ABL8WPS24200) In 380~500 VAC, Out 24 VDC, 20 Amp

    0 out of 5

    Model: ABL8WPS24200

    product or component type
    Power supply
    power supply type
    Regulated switch mode
    Nominal input voltage
    380…500 V AC three phase, terminal(s): L1, L2, L3
    rated power in W
    480W
    output voltage
    24 V DC
    power supply output current
    20A
    permissible temporary current boost
    1.5 x In (for 4 s)
    Power Factor
    0.65
    efficiency
    92%
    Output voltage adjustment
    24…28.8 V adjustable
    power dissipation in W
    38.4W
    Hold-up time
    >= 18 ms at 400 V
    provided equipment
    Power factor correction filter conforming to IEC 61000-3-2
    connections – terminals
    For diagnostic relay: removable screw terminal block, connection capacity: 2 x 2.5 mm
    For input connection: screw type terminals, connection capacity: 3 x 0.5…3 x 4 mm AWG 22…AWG 12
    For input ground connection: screw type terminals, connection capacity: 1 x 0.5…1 x 4 mm AWG 22…AWG 12
    For output connection: screw type terminals, connection capacity: 4 x 0.5…4 x 10 mm AWG 22…AWG 8
    status LED
    1 LED (green and red)output voltage:
    1 LED (green, red and orange)output current:
    depth
    160mm
    height
    143mm
    width
    96mm
    net weight
    1.6kg
    output coupling
    Series
    Parallel
    marking
    CE
    operating position
    Vertical



    Rs 39,000.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D115) 115 Amp

    5.00 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 45,000.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D12) 12 Amp

    0 out of 5

    Available voltage (must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 3,800.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D150) 150 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 52,000.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D18) 18 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 5,200.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D25) 25 Amp

    0 out of 5

    Available voltage (must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 6,900.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D32) 32 Amp

    0 out of 5

    Available voltage (must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 9,800.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D40A) 40 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    Rs 13,500.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D50A) 50 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    Rs 15,400.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D65A) 65 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    Rs 18,400.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D80) 80 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC
    • 24 V DC
    Rs 24,500.00
  • Schneider TeSys D Magnetic Contactor 3 pole (LC1D95) 95 Amp

    0 out of 5

    Available voltage ( must write any one in additional information/order notes)

    • 220 V AC
    • 110 V AC
    • 24 V AC

    24 V DC is on requirement/ price and specs are differ

    Rs 29,500.00
